The ACS712 is a Fully Integrated, Hall Effect-Based Linear AC/DC Current Sensor with 2.1 kV RMS Voltage Isolation and a Low-Resistance Current Conductor.
Features of 5AMP Hall Current Sensor Module:
Low-noise analog signal path.
5 µs output rise time in response to step input current.
50 kHz bandwidth.
Total output error 1.5% at TA= 25°C, and 4% at –40°C to 85°C.
Small footprint, low-profile SOIC8 package.
1.2 mΩ internal conductor resistance.
2.1 kV RMS minimum isolation voltage from pins 1-4 to pins 5-8.
5.0 V, single supply operation.
66 to 185 mV/A output sensitivity.
Output voltage proportional to AC or DC currents.
Factory-trimmed for accuracy.
Extremely stable output offset voltage.
Nearly zero magnetic hysteresis.
